Lightweight Flexible Solar Panel 560W
Products Description
Product Introduction: Our 560W flexible solar panel weighs only 2.9 kg/m², which is 30% lighter than traditional glass modules. With a thickness of 1.8mm (excluding the junction box), it is 50% thinner than conventional modules. The minimum bending radius reaches 0.3m, ensuring no battery fractures or power loss. As the industry's first hail-impact-resistant flexible monocrystalline silicon module system, it requires no mounting brackets and can be directly adhered to the original surface with structural adhesive for rapid installation. The surface color and patterns are customizable to meet architectural aesthetic requirements. Its anti-vibration design makes it the preferred choice for mobile energy and transportation hub photovoltaic modules.
Electrical performance parameters(STC)
|
parameter |
parameter value |
|
Max. Power(W) |
560 |
|
Max. Power Point Voltage(V) |
45.29 |
|
Max. Power Point Current(A) |
12.37 |
|
Open Circuit Voltage(V) |
53.05 |
|
Short Circuit Current(A) |
12.96 |
|
Weight(kg/piece) |
7.6 |
|
Mechanical Load(Pa) |
Front 5400Pa,Back 2400Pa |
|
Operating temperature range |
+40℃~+85℃ |
|
Component Efficiency(%) |
22.7 |
|
Output Power Tolerance |
0~+5W |
|
Temperature Coefficient of Pmax |
-0.29%/℃ |
|
Temperature Coefficient of Voc |
-0.26%/℃ |
|
Temperature Coefficient of Isc |
0.045%/℃ |
STC:Irradiance of 1000W/㎡, cell temperature of 25℃, and air mass 1.5 (AM1.5)
Scope of application
Based on the core advantages of light, thin, flexible, weather resistant, and efficient products, it is suitable for various scenarios, especially in areas where traditional rigid components are difficult to cover. The specific details are as follows:
1,Mobile energy field
Suitable for RVs, new energy vehicles, mobile charging equipment, portable power generation systems, etc., with lightweight and flexible component design, it can be installed on the body and equipment surface without occupying additional space, providing stable power supply for mobile devices; The characteristic of no hidden cracks under bending vibration can adapt to bumps and vibration scenes during movement.
2,Building Integrated Photovoltaics (BIPV)
Civil buildings: Roofs (especially curved roofs) and walls of villas and residences can replace traditional decorative materials, balancing power generation and aesthetics. Surface colors and patterns can be customized to suit different architectural styles.
Commercial buildings: The exterior facades and skylights of large buildings such as office buildings, shopping malls, and exhibition halls are designed with ultra-thin and lightweight components, which do not affect the load-bearing capacity of the building structure. At the same time, solar power generation is achieved to help buildings save energy and reduce consumption.
3,Transportation hub field
Suitable for areas such as high-speed railway stations, airports, subway stations, and highway service areas, it can be installed in bus shelters, ceilings, walls, and other areas to adapt to the vibration and frequent personnel flow of transportation hubs; Resistant to hail and wind pressure, it can cope with extreme outdoor weather and provide auxiliary power supply for transportation hubs.
4,Special scenario domain
Curved/irregular carriers: Container houses, temporary buildings, landscape buildings, and other irregular or curved structures with strong component flexibility that can be perfectly fitted and installed without the need for additional carrier modifications.
Extreme climate regions: cold regions (-40 ℃ low temperature environment), areas with frequent snow, hail, and strong winds. The components have strong weather resistance and can operate stably to ensure the continuity of power generation.
Lightweight demand scenarios: renovation of ancient buildings (requiring load control), temporary power generation projects, off grid photovoltaic systems in remote areas, with lightweight components and easy installation that can be quickly put into use.
5,Supplement to large-scale photovoltaic power plants
Can be used as a supplement to large-scale ground photovoltaic power stations and distributed photovoltaic power stations, for curved or irregular areas in power stations, or for power station expansion, fully utilizing idle space and increasing the total power generation of power stations; High voltage and high power characteristics, adaptable to power station system design, reducing system integration costs.
Product application of flexible solar panel 560W
Large span light steel factory building
Feature of Our Flexible Solar Panel 560W
Efficient power generation, worry free warranty
Outstanding conversion efficiency: up to 22.7%, using 182.2mm × 183.75mm Topcon batteries, with excellent power generation performance and higher power generation per unit area.
Stable and reliable power: power tolerance 0~+5W, first year attenuation<1%, 25 year output ≥ 89.4%, equipped with 25 year power+12 year quality assurance.
Adapting to complex lighting conditions: With outstanding anti occlusion ability, the temperature for occlusion testing is reduced by more than 30% compared to conventional components, and stable output is achieved under irradiance ranging from 200W/㎡ to 1000W/㎡.
Lightweight and flexible, easy to install
Ultimate Lightweight: Only 2.9kg/m2, 7.6kg per piece, 30% lighter than traditional glass components, significantly reducing installation load capacity.
Ultra thin design: With a thickness of only 1.8mm (excluding junction boxes), it is 50% thicker than traditional components, saving space and adapting to various special installation scenarios.
High flexibility: The minimum bending radius is 0.3m, and the battery cell has no hidden cracks or power attenuation under bending vibration, suitable for curved installation.
Quick installation: No need for brackets, can be directly pasted and fixed; 4mm ² and 400mm customizable output cables, compatible with MC4 connectors, easy to connect.
Super weather resistant, sturdy structure
Anti hail impact: the industry's first flexible crystalline silicon component that can withstand hail impact without hidden cracks and zero power attenuation; The hail test strictly follows the IEC standard, using a 25mm diameter ice ball and an impact velocity of 23m/s. After testing, the component structure is complete and the performance is stable.
Resistant to extreme environments: with a static load of 5400Pa on the front and 2400Pa on the back, it is not afraid of heavy snow and strong wind pressure, and can work normally at -40 ℃~+85 ℃.
High protection level: The junction box is IP68 protected, waterproof, dustproof, and corrosion-resistant; The back panel is available in black and white, and the surface color pattern can be customized, balancing practicality and aesthetics.
Stable and durable: Through multiple certifications such as ISO, TUV, CE, IEC, etc., the process is rigorous, the structure is stable, not easy to age, and the service life is long.
Excellent electrical performance and strong adaptability
High voltage adaptation: Maximum system voltage of 1500V DC (IEC standard), fuse rated current of 25A, suitable for large photovoltaic systems, reducing wiring costs.
Good temperature adaptability: peak power temperature coefficient -0.29%/℃, NOCT 45 ± 2 ℃, slow power generation efficiency degradation in high temperature environments.
Production of Our Solar Panel：
Our Service:
WE guarantee that we will reply to your inquiries/emails as soon as possible.
WE guarantee that we will provide you with products of the highest cost-performance ratio.
WE guarantee that we will provide you with professional and efficient services at any time.
WE guarantee that all products will be delivered on schedule.
WE guarantee one-stop service.
Why choose us?
1. 19 years experience.
2. Ensure the products meet the quality standards.
3. Ensure the goods will be delivered on time.
4. We will reply you within 24 hours.
5. Provide warm and friendly service and after-sale service.
6. Guaranteed the good quality and best service, as you buy from local supplier.
7.. Customized specifications are welcome.
FAQ
Q:What's the delivery time?
A: Within 20 days after deposit.
Q: What's the payment terms?
A: T/T 30% deposit, balanced before shipment.
Q: Are you factory or trading company?
A: We're factory, and can do exporting ourselves and trading others if you want JINKO.
Q:How's your capacity in your workshop?
A: We operate multiple production lines, featuring high production efficiency, fast delivery speed, guaranteed quality, and customizable services available.
Packing & Shipping
Hot Tags: lightweight flexible solar panel 560w, China lightweight flexible solar panel 560w manufacturers, suppliers, factory
