Description

Perkins diesel generators originate from the UK and have nearly a century of experience in power equipment research and manufacturing. They are a globally renowned supplier of diesel engines and power generation equipment. This series of generators is equipped with Perkins original 400/1100/1300 series diesel engines, integrating high-precision power generation modules and intelligent control systems, specially designed for global industrial, commercial, and emergency power supply scenarios, integrating core advantages such as efficient power generation, stable operation, and low noise environmental protection.

Product Parameter

Parameter Name	Parameter Value	Parameter Name	Parameter Value
Rated Power	10kW -1500kW (optional)	Rated Voltage	220V/380V/400V/480V (customizable with multiple voltage levels)
Rated Frequency	50Hz/60Hz (globally compatible)	Power Factor	0.8 (lag)
Engine Model	Perkins 404D-22/1104D-44T/1306C-E87TA and other original models	Starting Method	Electric start (24V)/fully automatic start/emergency start
Fuel Consumption Rate	200g/kW · h -215g/kW · h (under rated load)	Fuel Tank Capacity	40L -800L (depending on the model, expandable)
Noise Level	Standard 75-82dB (A)/Super Silent 68-75dB (A)	Protection Level	IP23 (standard type)/IP54 (rain and dust proof type)/IP65 (high protection type)
Operating Temperature	-30 ℃~+50 ℃ (suitable for extreme environments)	Storage Temperature	-40℃ ~ +65℃
Control Mode	Manual/automatic/remote control (optional ATS switching, parallel operation)	Weight	400kg -12000kg (depending on power level)

Note: The above are standard parameters, parameters of different power models are slightly different, and models can be selected or special configurations customized according to customer needs.

Product feature and application

Key Features of Our Perkins Diesel Generator

Genuine British Power, High Efficiency&Energy Saving :

Equipped with Perkins original diesel engine, advanced electronic fuel injection technology and combustion optimization system, the fuel consumption rate is as low as 200g/kW · h, saving 8% -12% energy compared to similar products, and significantly reducing long-term operating costs; The power output is stable, with an overload capacity of 110%, which can handle sudden load demands with ease.

Stable&Reliable, Wide Working Condition Adaptability:

Tested in harsh environments such as -30 ℃ low temperature,+50 ℃ high temperature, high dust, and high humidity, with a protection level of up to IP65, suitable for various complex working conditions; Using high-strength alloy cylinder body and high-quality components, the failure rate is extremely low, and the service life is over 12 years, meeting the requirements of continuous operation.

Ultra Low Noise, Environmental Compliance:

Relying on Perkins engine's native noise reduction technology, combined with double-layer soundproof covers, high-efficiency mufflers, and maze style intake and exhaust structures, the standard unit noise is as low as 75dB (A), and the super quiet type can be reduced to 68dB (A). The operating noise is much lower than the industry average level; Compliant with international environmental standards such as Euro V and EPA Tier 4 Final, with emissions meeting standards and adapting to global environmental regulations.

Intelligent Control, Easy Operation&Maintenance:

Equipped with Perkins intelligent control system, high-definition LCD display screen in Chinese and English monitors key parameters such as speed, voltage, fuel consumption, water temperature in real time, supporting automatic fault diagnosis, warning and recording; Optional remote monitoring module enables remote start stop, data viewing, and fault reporting without the need for manual duty, significantly reducing operation and maintenance costs.

Flexible Customization, Global Adaptation:

Power coverage of 10kW-1500kW, support for 50Hz/60Hz frequency and multi voltage level customization, can be matched with accessories such as soundproof cover, large capacity fuel tank, ATS automatic switch, parallel control cabinet, etc; Complies with international certification standards such as IEC, UL, CE, GOST, etc., and adapts to the power grid and regulatory requirements of different countries and regions around the world such as Europe, America, Asia, Oceania, etc.

Product Model

50hz

Model	Common power (kVA/kW)		Standby power (kVA/kW)		Engine type	Dimension(mm)	Weight (kg)
TPD9P5-1	9	7	10	8	403A-11 G1	1950×800×1115	560
TPD9P5-2	9	7	10	8	403D-11G	1950×800×1115	560
TPD13P5-1	13	10	14	11	403A-15G1	1950×800×1115	700
TPD13P5-2	13	10	14	11	403D-15G	1950×800×1215	700
TPD15P5	15	12	16	13	403A-15G2	1950×800×1215	760
TPD20P5-1	20	16	22	18	404A-22G1	2100×740×1115	740
TPD20P5-2	20	16	22	18	404D-22G	2100×740×1115	740
TPD27P5	27	22	30	24	404D-22TG	2300×980×1270	780
TPD30P5	30	24	32	26	1103A-33G	2300×980×1270	1250
TPD45P5	45	36	50	40	1103A-33TG1	2600×1130×1540	1360
TPD60P5	60	48	66	53	1103A-33TG2	2600×1130×1540	1580
TPD65P5	65	52	72	57	1104A-44TG1	2800×1130×1560	1580
TPD80P5-1	80	64	88	70	1104A-44TG2	2800×1130×1560	1580
TPD80P5-2	80	64	88	70	1104C-44TAG1	2800×1130×1560	1600
TPD100P5	100	80	110	88	1104C-44TAG2	2800×1130×1560	1720
TPD135P5	135	108	150	120	1106A-70TG1	3200×1130×1715	2215
TPD150P5	150	120	165	132	1106A-70TAG2	3600×1130×2105	2215
TPD180P5	180	144	200	160	1106A-70TAG3	3600×1130×2105	2385
TPD200P5	200	160	220	176	1106A-70TAG4	3600×1130×2105	2450
TPD231P5	231	185	254	203	1506A-E88TAG2	4000×1422×2190	3485
TPD257P5	257	206	283	226	1506A-E88TAG3	4000×1422×2190	3485
TPD307P5	307	246	338	270	1506A-E88TAG5	4000×1422×2190	3625
TPD350P5	350	280	400	320	2206C-E13TAG2	4400×1422×2450	4290
TPD400P5	400	320	450	360	2206C-E13TAG3	4400×1422×2450	4290
TPD455P5	455	364	500	400	2506C-E15TAG1	4600×1422×2530	5070
TPD500P5	500	400	550	440	2506C-E 15TAG2	4600×1422×2530	5070
TPD591P5	591	473	650	520	2806C-E 18TAG 1A	4800×1822×2522	6000
TPD650P5	650	520	700	560	2806A-E18TAG2	4800×1822×2522	6050
TPD746P5	746	597	820	656	4006-23TAG2A	6059×2438×2591	8250
TPD800P5	800	640	880	704	4006-23TAG3A	6059×2438×2591	8250
TPD910P5	910	728	1001	800	4008TAG1A	6059×2438×2591	9820
TPD1022P5-1	1022	818	1125	900	4008TAG2A	6059×2438×2591	9820
TPD1022P5-2	1022	818	1125	900	4008TAG2	6059×2438×2591	9820
TPD1125P5	1125	900	1250	1000	4008-30TAG3	6059×2438×2591	9820
TPD1250P5-1	1250	1000	1375	1100	4012-46TWG2A	40FT	12900
TPD1250P5-2	1250	1000	1375	1100	4012-46TWG2	40FT	12900
TPD1375P5	1375	1100	1500	1200	4012-46TWG3A	40FT	13000
TPD1500P5	1500	1200	1650	1320	4012-46TAG2A	40FT	13000
TPD1688P5	1688	1350	1850	1480	4012-46TAG3A	40FT	13000
TPD1850P5	1850	1480	2000	1600	4016TAG1A	40FT	16100
TPD2000P5-1	2000	1600	2200	1760	4016TAG2A	40FT	16100
TPD2000P5-2	2000	1600	2200	1760	4016-61TRG2	40FT	16100
TPD2250P5	2250	1800	2500	2000	4016-61TRG3	40FT	16200

60hz

Model	Common power (kVA/kW)		Standby power (kVA/kW)		Engine type	Dimension(mm)	Weight (kg)
TPD11P6	11	9	13	10	403D-11G	1950×800×1115	560
TPD15P6	15	12	16	13	403D-15G	1950×800×1215	700
TPD17P6	17	14	19	15	403A-15G2	1950×800×1215	760
TPD24P6	24	19	26	21	404D-22G	2100×740×1115	740
TPD33P6	33	26	35	29	404D-22TG	2100×740×1115	740
TPD35P6	35	28	38	30	1103A-33G	2300×980×1270	1250
TPD54P6	54	43	59	47	1103A-33TG1	2600×1130×1540	1360
TPD68P6	68	55	75	60	1103A-33TG2	2600×1130×1540	1580
TPD76P6	76	61	84	67	1104A-44TG1	2800×1130×1560	1580
TPD90P6-1	90	73	100	80	1104A-44TG2	2800×1130×1560	1580
TPD90P6-2	90	72	100	80	1104C-44TAG1	2800×1130×1560	1600
TPD115P6	115	92	125	100	1104C-44TAG2	2800×1130×1560	1720
TPD152P6	152	122	169	135	1106A-70TG1	3200×1130×1715	2215
TPD169P6	169	135	188	150	1106A-70TAG2	3600×1130×2105	2215
TPD197P6	197	158	219	175	1106A-70TAG3	3600×1130×2105	2385
TPD248P6	248	198	273	218	1506A-E88TAG2	4000×1422×2190	3485
TPD290P6	290	232	320	256	1506A-E88TAG3	4000×1422×2190	3485
TPD352P6	352	282	390	312	1506A-E88TAG5	4000×1422×2190	3625
TPD400P6-1	400	320	438	350	2206C-E13TAG2	4400×1422×2450	4290
TPD400P6-2	400	320	438	350	2206C-E13TAG3	4400×1422×2450	4290
TPD500P6-1	500	400	563	450	2506C-E15TAG1	4600×1422×2530	5070
TPD500P6-2	500	400	563	450	2506C-E 15TAG2	4600×1422×2530	5070
TPD625P6-1	625	500	687	550	2806C-E 18TAG 1A	4800×1822×2522	6000
TPD625P6-2	625	500	687	550	2806A-E18TAG2	4800×1822×2522	6000
TPD750P6	750	600	825	660	4006-23TAG2A	20GP	8250
TPD849P6	849	679	940	750	4006-23TAG3A	20GP	8250
TPD1001P6	1001	801	1103	883	4008TAG2	20GP	9820
TPD1250P6	1250	1000	1375	1100	4012-46TWG2A	40FT	12900
TPD1375P6	1375	1100	1500	1200	4012-46TWG3A	40FT	13000
TPD1500P6	1500	1200	1650	1320	4012-46TAG2A	40FT	13000
TPD1690P6	1690	1350	1850	1480	4012-46TAG3A	40FT	13000

Product Certification

Perkins diesel generators rely on Perkins' rigorous global quality control system, have passed multiple international authoritative certifications, complete qualifications, and can smoothly enter the global market with absolute quality assurance

FAQ

Q: Which countries' power grid standards and environmental requirements can this generator be adapted to?

A: The product supports customization of multiple voltage levels such as 50Hz/60Hz frequency and 220V/380V/400V/480V, and complies with international power grid standards such as IEC, UL, CE, GOST, etc. It can perfectly adapt to the power grid needs of most countries and regions around the world such as Europe, America, Asia, Oceania, etc; At the same time, it has passed international environmental certifications such as Euro V and EPA Tier 4 Final, achieving emission standards and meeting the environmental regulations of different countries.

Q: What is the fuel consumption rate of the generator? Is there an advantage in operating costs?

A: The generator is equipped with a Perkins high-efficiency energy-saving engine, which has a fuel consumption rate as low as 200g/kW · h under rated load, saving 8% -12% energy compared to products of the same level; Simultaneously adopting an intelligent fuel management system, the fuel supply can be automatically adjusted according to load changes to avoid ineffective fuel consumption; Paired with original imported filter cartridges, the engine has minimal wear and tear, low maintenance costs, and significant advantages in long-term operating costs.

Q: Does the product support remote monitoring and automatic start stop? How to achieve it?

A: Supports remote monitoring and automatic start stop function. Perkins intelligent remote monitoring module can be optionally selected to achieve remote monitoring of generator operating parameters, fault alarms, remote start stop and parameter settings through mobile APP or computer client; Equipped with ATS automatic switch, the generator can be automatically started for power supply when the power grid is cut off. After the power grid is restored, it will automatically switch and stop without manual intervention, achieving unmanned operation.

Q: Can I customize the generator configuration according to my needs? For example, silent hood, fuel tank capacity, etc.

A: Okay. We support comprehensive personalized customization services, and can choose core configurations such as power level, voltage frequency, and startup mode according to customer needs; At the same time, accessories such as silent cover, large capacity fuel tank, ATS automatic switch, remote monitoring module, rain and dust cover, parallel control cabinet, etc. can be installed; For special working conditions such as low temperature and high dust, exclusive configurations such as low-temperature start-up kits and high protection level enclosures can be customized. The customization cycle is generally 18-30 working days, and specific details can be discussed with the sales team.
